How Taper Line, Inc.’s Locknuts Operate

By applying torque to the locking screws a “Press Fit “or “wave Spring” effect is created thus locking the female threads of the locknut (C) to the male threads of the shaft. This deflection produces a strong mechanical metal to metal lock but does not affect the squareness of the bearing face (A) to the pitch diameter of the locknut threads. By releasing the locking screws (with hex style wrench) the “Wave Spring” thread section springs back the normal thread clearance position thereby allowing the nut to be adjusted or removed. At no time should the tapped holes of the locknut be altered or modified. The locking screws may extend beyond the locking surface (B) on some face lock style locknuts after locking – consult Taper Line, Inc

Shaft Dimensions for Inch Standard and Piloted Locknuts

Please see below for product recommendations based on your required dimensions in inches:

If your required dimensions are in metric units please click here.

TLN
HTLN
BEARING
BORE NO.
BEARING BORE
A-NOM.
BB1C
MAX
EXTENSION
D-MAX
MAJOR DIA.PITCH DIA.MINOR DIA.
MAX.
THREADS
PER INCH
000.3937.375.531.312.391-.3856.3707/.3681.352732
011.4724.375.531.406.469-.4636.4487/.4461.430732
022.5906.406.593.500.125.586-.5806.5657/.5627.547732
033.6693.406.593.562.125.664-.6586.6437-.6407.625732
044.7874.438.625.718.125.781-.7756.7607-.7573.742732
055.9843.468.688.875.125.969-.9636.9487-.9453.930732
0661.1811.468.6881.062.1251.173-1.16481.1369-1.13291.104818
0650651.3125.500.7181.187.1251.312-1.30431.2764/1.27241.244318
077i1.3780.500.7181.250.1251.376-1.36781.3399-.1.33591.307818
0881.5748.531.7181.468.1251.563-1.55481.5269-1.52241.494818
0991.7717.531.7181.688.1251.767-1.75881.7309-1.72641.698818
10101.9685.594.8441.875.1561.967-1.95881.9309-1.92641.898818
11112.1654.594.8442.062.1562.157-2.14882.1209-2.11582.088818
12122.3622.625.9062.250.1562.360-2.35182.3239-2.31882.291818
13132.5591.641.9382.438.1562.548-2.53982.5119-2.50682.479818
14142.7559.641.9382.625.1882.751-2.74282.7149-2.70982.682818
15152.9528.6881.0002.781.1882.933-2.92182.8789-2.87352.830812
16163.1496.6881.0003.000.1883.137-3.12583.0829-3.07703.034812
17173.3465.7181.0313.188.2183.340-3.32883.2859-3.28003.237812
18183.5433.8121.1563.375.2183.527-3.51583.4729-3.46553.424812
19193.7402.8441.2193.562.2503.730-3.71883.6759-3.66853.627812
20203.9370.8751.2503.781.2813.918-3.90683.8639-3.85653.815812
21214.1339.8751.2503.938.2814.122-4.11084.0679-4.05964.019812
22224.3307.9061.3124.188.3124.325-4.31384.2709-4.26264.222812
24244.7244.9381.3434.562.3444.716-4.70484.6619-4.65364.613812
26265.11811.0004.938.4065.106-5.09485.0519-5.04365.003812
28285.51181.0625.312.4065.497-5.48585.4429-5.43465.394812
30305.90551.1255.718.4065.888-5.87685.8339-5.82565.785812
32326.29921.1886.125.4386.284-6.26786.2029-6.19386.13068
34346.69291.2816.500.4386.659-6.64386.5778-6.56876.50568
36367.08661.2506.906.4387.066-7.05086.9848-6.97576.91268
38387.48031.2817.312.4387.472-7.45687.3908-7.38177.31868
40407.87401.3447.688.5007.847-7.83187.7658-7.75447.69388
44448.66141.4068.312.5628.628-8.61238.5468-8.53478.47468

Shaft Dimensions for Metric Standard and Piloted Locknuts

Please see below for product recommendations based on your required dimensions in metric units:

If your required dimensions are in inches please click here.

TLNKM
HTLNKM
BEARING-
BORE NO.
BEARING BORE
A-NOM.
BB2C
MAX
EXTENSION
D-MAX
MAJOR DIA.PITCH DIA.MINOR DIA.
MAX.
0001010,014,59,010,000-9,9109,513-94509,080
0111210,014,510,412,000-11,88811,350-11,27510,773
0221510,715,513,43,1815,000-14,888 14,350-14,27513,773
0331711,015,514,273,1817,000-16,88816,350-16,27515,773
0442012,017,018,243,1820,000-19,88819,350-19,27518,773
05-152513,519,022,233,1825,000-24,88824,350-24,27023,773
0552513,519,022,233,1825,000-24,85024,026-23,93023,159
0663013,519,026,973,1830,000-29,85029,026-28,93028,159
0650653214,019,529,63,1832,000-31,85031,026-30,93030,159
0773514,019,531,753,1835,000-34,85034,026-33,93033,159
0884014,019,537,293,1840,000-39,85039,026-38,93038,159
0994514,019,542,883,1845,000-44,85044,026-43,39043,159
10105016,022,547,633,9650,000-49,85049,026-48,92548,159
11115517,023,552,373,9655,000-54,82053,701-53,58952,546
12126017,524,557,153,9660,000-59,82058,701-58,58957,546
13136518,025,061,933,9665,000-64,82063,701-63,58962,546
14147018,025,066,684,7870,000-69,82068,701-68,58967,546
15157519,026,570,644,7875,000-74,82073,701-73,58972,546
16168019,026,576,204,7880,000-79,82078,701-78,58977,546
17178520,028,080,985,5485,000-84,82083,701-83,58982,546
18189022,030,585,735,5490,000-89,82088,701-88,58987,546
1999523,032,090,476,3595,000-94,82093,701-93,58392,546
202010024,033,596,047,14100,000-99,82098,701-98,58397,546
212110524,033,5100,037,14105,000-104,820103,701-103,583102,546
222211025,035,0106,387,92110,000-109,820108,701-108,583107,546
242412026,035,0115,878,74120,000-119,820118,701-118,583117,546
262613027,0125,4310,31130,000-129,820128,701-128,583127,546
282814029,0134,9210,31140,000-139,820138,701-138,583137,546
303015029,0145,2410,31150,000-149,820148,701-148,583147,546
323216030,0155,5811,13160,000-159,764158,051-157,911156,319
343417031,0165,1011,13170,000-169,764168,051-167,911166,319
363618032,0175,4111,13180,000-179,764178,051-177,911176,319
383819033,0185,7211,13190,000-189,764188,051-187,891186,319
404020034,0195,2812,70200,000-199,764198,051-197,891196,319
